Technical Data
Displacement (1450rpm 50Hz)：26,84 m3/h
Displacement (1750rpm 60Hz)：32,39 m3/h
No. of cylinder x bore x stroke：4 x 50 mm x 39,3 mm
Weight：94 kg
Max. pressure (LP/HP)：19 / 32bar
Connection suction line：28 mm – 1 1/8”
Connection discharge line：22 mm – 7/8”
Oil type R134a/R407C/R404A/R507A/R407A/R407F：BSE32(Standard) | R134a tc>70°C: BSE55 (Option)
Oil type R22 (R12/R502)：B5.2 (Option)
Oil type R1234yf：BSE32 (Standard) | R1234yf tc>70°C : BSE55 (Option)
Oil type R1234ze：BSE55 (Standard) | to>15°C: BSE85K (Option) | tc>70°C: BSE85K (Option)
Oil type R454C/R455A：BSE32 (Standard)
Oil type R515B：BSE55 (Standard) | to>15°C: BSE85K (Option) | tc>70°C: BSE85K (Option)
Motor data
Motor version：2
Motor voltage (more on request)：380-420V Y-3-50Hz
Max. operating current：14.5 A
Starting current (Rotor locked)：62.2 A
Max. power input：8,1 kW
