1：Technical Data
Displacement (1450rpm 50Hz)：126,8 m³/h
Displacement (1750rpm 60Hz)：153,0 m³/h
No. of cylinder x bore x stroke：6 x 75 mm x 55 mm
Weight：230 kg
Max. pressure (LP/HP)：19 / 32 bar
Connection suction line：54 mm – 2 1/8”
Connection discharge line：35 mm – 1 3/8”
Oil type R134a/R407C/R404A/R507A/R407A/R407F：BSE32(Standard) | R134a tc>70°C: BSE55 (Option)
Oil type R22 (R12/R502)：B5.2(Option)
Oil type R1234yf BSE32 (Standard) | R1234yf tc>70°C：BSE55 (Option)
Oil type R1234ze BSE55 (Standard) | to>15°C：BSE85K (Option) | tc>70°C: BSE85K (Option)
Oil type R454C/R455A： BSE32 (Standard)
Oil type R515B：BSE55 (Standard) | to>15°C: BSE85K (Option) | tc>70°C: BSE85K (Option)
Oil charge：4,75 dm³
2：Motor data
Motor version：2
Motor voltage (more on request)：380-420V PW-3-50Hz
Max. operating current：65.5 A
Winding ratio：50/50
Starting current (Rotor locked)：141.0 A Y / 233.0 A YY
Max. power input ：40,0 kW
