1：Technical Data
Displacement (1450rpm 50Hz)：110,5 m³/h
Displacement (1750rpm 60Hz)：133,4 m³/h
No. of cylinder x bore x stroke ：6 x 70 mm x 55 mm
Weight：233 kg
Max. pressure (LP/HP)：19 / 32 bar
Connection suction line：54 mm – 2 1/8”
Connection discharge line：35 mm – 1 3/8”
Oil type R134a/R407C/R404A/R507A/R407A/R407F：BSE32(Standard)
Oil charge：4,75 dm³
2：Motor data
Motor version：2
Motor voltage (more on request)：380-420V PW-3-50Hz
Max. operating current：53.2 A
Winding ratio：50/50
Starting current (Rotor locked)：141.0 A Y / 233.0 A YY
Max. power input ：33,0 kW
